Input Voltage: 120V AC ±10%
-
Input Frequency: 60Hz
-
Adjustable Output: 10V–16V DC ±0.5 Volts
-
Output Current: 100 Amps DC Continuous (Maximum)
-
Line Regulation: ±5%
-
Load Regulation: ±5%
-
Efficiency: ±85%
-
Overload Protection: 20A/250V Fuse Input Voltage
-
Output Ripple: 150mV RMS
-
Design: Switching Type
-
Protection Temperature: 75°C
-
Cooling Fan: 4 pieces (40x40x10mm)
-
Input Cable: SVT 14 AWG 85 C 6 Feet
-
Power Switch: 15A | 250 VAC
-
Net Weight (1): Approx. 3.86kg
-
Dimensions: 297.5 x 247 x 66.5mm
-
Includes Digital Voltmeter
